Protectli FW6A/B/C 2U · five keystones
Protectli FW6A carrier · five RJ45 keystone slots
Specifications
- Rack height
- 2U
- Depth
- 130.1 mm
- Mounting
- 3D-printed carrier
- Connectable Ethernet ports
- 5
Hardware specifications
| Specifications | |
|---|---|
| Dimensions | 250 × 130.1 × 88 mm (W × D × H)1 |
| Rack space | 2U1 |
Specifications reviewed 2026-10-05. Hardware revisions and configurations vary; check the sources for your exact unit.
Model & configuration
FW6A rests on the 30.4 mm bay floor and slides through the faceplate window, which follows the FW6 front-plate profile (31.4–82.9 mm high, up to 153.8 mm wide): front flush with the faceplate, 1.1 mm clear of the rear lip at 127.65 mm. Protectli's 154.6 mm plate makes it a press fit of about 0.4 mm per side, shown as contact in the overlap check; physical fit is not certified. FW6B/C share the enclosure but are not catalogued separately; VP2420 and VP6630 are not registered as substitutes. Five generic RJ45 couplers seated at the measured openings; front and rear cabling available. Check print tolerances and hardware revision before printing.
Power reference
- passive
- 0 W
- passive
- 0 W
Passive rack hardware. Installed devices are counted separately.
Product & source links
Download printable model3D model attribution
- Creator
- Not recorded
- Licence
- Not recorded — check the original model page
