UniFi UCG-Fiber 1U tray

Specifications

Rack height

1U

Depth

129.8 mm

Mounting

3D-printed 1U tray

Hardware specifications

Dimensions

254.0 × 129.8 × 44.5 mm (W × D × H) Source

Rack space

1U Source

Variant

UCG-Fiber 10i RM NC (no front cable cutout; screws directly into plastic) Source

Inner width

213.5 mm for the 212.8 mm UCG-Fiber Source

Specifications reviewed 2026-10-06.

Model & configuration

Gateway rests on the 6.95 mm floor with its front against the faceplate; the status display shows through the 200 mm faceplate window. The rear is open; the optional Back plate.stl from the same model was not supplied. Overall 1U; populated top at about 37 mm. Check print tolerances; version 1.1 of the design adds 0.2 mm internal clearance.

Dimensions describe the catalogue model or configured rack allowance. Check your exact hardware revision.

Power reference

0 W (passive) – 0 W (passive)

Passive rack hardware. Installed devices are counted separately.

Links & downloads

3D model attribution

Creator

Maurício Pessoa (Mauker)

Licence

CC BY-NC-SA
