UniFi USW-Flex-Mini 1U tray

Specifications

Rack height

1U

Depth

74 mm

Mounting

3D-printed 1U tray

Hardware specifications

Dimensions

254.0 × 74.0 × 44.5 mm (W × D × H) Source

Rack space

1U Source

Variant

Single USW-Flex-Mini 10-inch rack mount Source

Inner width

107.6 × 21.6 mm window for the 107.2 × 21.2 mm switch Source

Specifications reviewed 2026-10-06.

Model & configuration

The supplied STL is offset 111.12 mm along X; it is re-centred before the axis change. The faceplate window follows the switch front profile (107.6 × 21.6 mm, bottom at 11.45 mm, 3.1 mm right of centre): the switch slides through with its ports flush with the faceplate front inside the 74 mm frame. Four corner cradles at the front and rear cup the switch's rounded lower corners; the overlap check shows them as contact. Overall 1U. Check print tolerances; the published double-switch variant is not included.

Dimensions describe the catalogue model or configured rack allowance. Check your exact hardware revision.

Power reference

0 W (passive) – 0 W (passive)

Passive rack hardware. Installed devices are counted separately.

Links & downloads

3D model attribution

Creator

Maurício Pessoa (Mauker)

Licence

CC BY-NC
